WebSockets by MediaMongrels - Toolkit for LabVIEW Download

Library for communicating using WebSockets

Watch

9

15,873

screenshot

Version	2.0.2.41
Released	Dec 13, 2023
Publisher	MediaMongrels
License	MIT
LabVIEW Version	LabVIEW>=13.0
Operating System	Windows, Mac, and Linux
Used By	mediamongrels_ltd_lib_websockets_secure_addon samangh_lib_wamplv_wamp_client labview_open_source_project_lib_mqtt_websockets_connection
Project links	Homepage Documentation Repository

Description

This library implements WebSockets Client and Server functionality for communicating between LabVIEW applications and between a LabVIEW Application and a WebSockets Client (e.g. web-browser) and Server (e.g. 3rd Party Services using WebSockets).

Release Notes

2.0.2.41 (Dec 13, 2023)

[Fix: 7] Handshake header is now case-insensitive match as per RFC2616
[Fix: 9] Fix for an infinite loop on Read is no connection (no socket)

2.0.1.40 (Feb 25, 2020)

- Fix issue where the Sec-WebSocket-Key is not correctly generated (not Base64-encoded)

samsharp99 was a contributor to this release

2.0.0.38 (Sep 09, 2019)

Major rewrite of the WebSockets library:
- New: Moved library to an OO approach for WebSockets connections (Client/Server Classes)
- New: Abstracted underlying socket functionality (e.g. NI VISA TCP) for future secure WebSockets support
- New: Added TCP socket listener for listening for server socket connections
- New: Simplified API
- New: Added high-level Read function which internally handles fragmented and Ping frames
- New: Added WebSockets Client Example VI and modified examples to use new classes
- New: Added unit testing to source repository
- New: Added detailed documentation (.chm file) to LabVIEW Help menu and added examples to NI Example Finder
- New: Added palette support for LV2020
- Fix: Fixed incorrectly applied timeout values (timeout = approx. maximum time until VI returns)
- Fix: WebSocket-Client-Key is now correctly generated as a random string rather than being a constant

Note: A backwards compatibility layer is retained for legacy applications allowing upgrade with minimal application changes. It is strongly recommended to update applications to use the new library VIs.

samsharp99 was a contributor to this release

1.7.4.26 (Nov 28, 2018)

- Fixed incorrect detection of multi-frame packets in Read.vi (thanks to ANDRÉ_CARVALHO)

samsharp99 was a contributor to this release

1.7.1.24 (Jan 12, 2018)

- Added better support for Opcodes defined in RFC6455: Now supports reading/writing of PING/PONG frames and reading/writing of fragmented messages (opcode 0x0). Payload data will be returned for supported opcodes.
- Improved error handling of unsupported opcodes
- Replaced Opcode with Ring type-def
- Added 'Request URI' input to InitiateClientHandshake (defaults to '/') to improve compatibility with 3rd party WS servers
- Fixed timeout not being passed to subsequent TCP VIs in Read.vi

samsharp99 was a contributor to this release

1.6.0.22 (Oct 18, 2016)

- Fixed an issue with incorrect EOL being used in InitiateClientHandshake.vi (better cross-platform support)
- Added support for sending additional headers in the client handshake / server response
- Added support for Sec-WebSocket-Protocol: The DoHandshake VI now has a 'supported protocols' input which allows (in order of preference) specification of supported protocols. If a supported protocol is found in the received header, it will be returned back to the client as per the WebSocket specification.

Note: The VI Package has changed name - please uninstall any previous versions of this package.

samsharp99 was a contributor to this release

Show all release notes (+5 more releases)
